4-in-1 Laser Machine

4-in-1 laser machine: welding, cutting, cleaning, and welding seam treatment

The Smart-P3000W is a high-performance fiber laser cutting system featuring a 3000W BWT fiber laser source and a next-generation Relfar laser head. It is equipped with a double wire feeder, Schneider electrical components, and an extended 20-meter fiber cable for enhanced operational flexibility. The machine incorporates an ultra-lightweight, compact design with an oscillating light spot and safety circuit trigger protection. It offers user-friendly touch screen control with a multi-language interface and an integrated, portable body on universal casters. The system also includes a Hanli/S&A water chiller and an intelligent wire feeding mechanism for efficient and reliable performance.

4-in-1 Laser Machine Features:

1. Cost-Effective Multifunctionality: The 1.4 in 1 multifunctional device offers exceptional value for money, making it your top choice for versatility and economy.

2. Smart Internal Design: The device features a smart internal design with an interactive control system that broadens the tolerance range of processed parts and the width of the weld seam (0-6mm). This innovation overcomes the limitations of a small light spot, ensuring a superior weld seam quality.

3. Ergonomic Comfort: The lightweight construction and ergonomic design ensure a comfortable grip and easy one-handed control, enhancing user experience and efficiency.

4. User-Friendly Operation: The device is simple to operate and easy to use, eliminating the need for experienced workers. Even new workers can handle it with ease.

5. Safety Features: Equipped with multiple safety alarms, the device automatically locks the light when the work piece is removed, ensuring high safety standards.

6. Aesthetic and Efficient Welding: The device produces beautiful welding seams at a fast speed, with no welding marks, no deformation, no blackening, and strong welding. It eliminates the need for grinding or later polishing, and requires minimal consumables.

7.Versatile Nozzle Configurations: The device can be fitted with various angle nozzles to meet the welding needs of different products, ensuring adaptability and efficiency.

8. Flexible Welding Head: The swing welding head allows for welding at any angle or shape, providing unparalleled flexibility and precision in welding applications.



Performance characteristics

1. Versatile Material Compatibility: Suitable for a wide range of metal materials, including carbon steel, stainless steel, high-strength steel, aluminum, copper, and various alloy materials.

2. Flexible Laser Output: The device can emit light continuously or in pulses, supporting both thermal conduction and continuous deep penetration. It can perform spot welding, butt welding, stitch welding, sealing welding, seam welding, as well as cleaning and cutting tasks.

3. Advanced Fiber Laser Technology: Equipped with a continuous fiber laser, it offers excellent beam quality, maintenance-free operation, and a high electro-optical conversion efficiency of over 25%. The pump source has a lifespan exceeding 100,000 hours.

4. High Processing Efficiency: The device boasts a fast processing speed, significantly improving productivity and efficiency in various applications.





Technical data

Model	Smart-W1500	Smart-W2000	Smart-W3000
Laser type	Continuous fiber laser
Rated output power	1500W	2000W	3000W
Power adjustment range	10%~100%
Applicable wavelength	1070 nm
output method	Continuous/modulation
Maximum modulation frequency	50kHz
Power instability	<3%
Max air pressure	15 Bar
Fiber output interface	QBH
Indicating system	Red light
Fiber length	15mm
Fiber cable length	20m
Torch type	4 in 1 laser head
Collimated focal length	60mm
Focus focal length	150mm
Spot adjustment range	0-8mm



Torch weight	0.7 kg
Protective gas method	Coaxial protection
Adjustable weld width	0~6mm
Water flow	>15L/min		>25L/min	>30L/min
product structure	Standard/ Mini
Product size L*D*H	1200*600*1300mm/ 680*590*1140mm
product weight	160kg/150kg
Working temperature	10~40℃
Working environment humidity	<70%
Operating Voltage	Single phase 220VAC			Three-phase five-wire 380VACSingle phase 220VAC
Total power	<7kw	<9.5 kw		<16 kw



 Laser Power Source

Wire Feeding System

4-in-1 Laser Machine Features of laser head:

1. Easy Installation and Longevity: Simple to install, with a long service life, low noise levels, and low energy consumption, ensuring efficient and reliable performance.

2. Compact and Powerful: Small in size and lightweight, yet capable of delivering high torque. It is designed for long-distance handheld welding and wire feeding, offering flexibility and convenience.

3. Synchronized Feeding and Welding Control: The wire feeding and welding processes are precisely synchronized. The wire feeding is stable and adjustable, making it adaptable to various scenarios. Operators can easily master the system, quickly get started, and achieve proficient operation.

4. Software-Controlled Feeding: The system is controlled by software, allowing the user to design and adjust wire feeding speed parameters via the control screen. Multiple sets of data can be saved and easily recalled for different welding tasks.

5. User-Friendly Control Screen: The visible control screen is intuitive and easy to use, simplifying the setup process and enhancing user experience.

6. Dual Wire Feeder: Equipped with a dual wire feeder, enhancing versatility and efficiency in welding operations.



Control System



Laser Head

Cooling system

1. Advanced Three-Layer Condenser Technology: The three-layer condenser sub-technology provides a large cooling capacity and excellent heat dissipation, ensuring the equipment remains durable even in harsh operating conditions.

2. High-Quality Water and Precision Care: The system uses high-quality water and maintains high precision, ensuring meticulous care for the laser components and significantly extending their service life.

3. Automatic Heating Function: With automatic heating technology, the system reduces the warm-up time for customers when starting the laser in winter, thereby enhancing overall production efficiency.

4. Aesthetic Arc-Shaped Design: The arc-shaped design not only looks elegant but also improves the overall matching grade of the laser equipment, enhancing its visual appeal and integration with modern industrial settings.

5. Energy-Efficient Operation: The equipment is designed to be energy-saving and electricity-saving, effectively reducing production costs for customers and promoting sustainable operations.

6. Flexible Matching Options: Available in high, medium, and low configurations to meet the diverse needs of customers, ensuring the right balance of performance and cost-effectiveness.
